Product Description

DJI Matrice 3TD for Dock 2 w/ DJI Care Enterprise

DESCRIPTION

The DJI Matrice 3TD is a cutting-edge drone specifically designed to work seamlessly with DJI Dock 2, providing unmatched capabilities for security and inspection operations. Outfitted with a wide-angle camera, a telephoto camera, and a thermal camera, the Matrice 3TD captures both visible and thermal images, offering exceptional versatility for professionals in infrastructure monitoring, industrial inspection, and surveillance.

Engineered for reliability, the Matrice 3TD boasts a rugged IP54-rated body, 50 minutes of maximum flight time, and a 10km effective operating radius. Its integrated RTK module ensures centimeter-level positioning accuracy, making it ideal for precision-critical operations. With 6-directional obstacle sensing and 400 battery cycles, this drone is built to deliver consistent performance even in demanding conditions.

Please Note: The DJI Matrice 3TD cannot operate as a standalone unit and requires DJI Dock 2 for functionality.

• Designed specifically for DJI Dock 2

  640x512 Thermal Camera

  50-min Max Flight Time

  IP54 Ingress Protection

  400 Battery Cycles

  10km Max Effective Operating Radius

  Integrated RTK Module

  6-Directional Obstacle Sensing

Key Features

• High-Resolution Imaging: Equipped with wide-angle (48MP), telephoto (12MP), and thermal (640x512 resolution) cameras for detailed data collection.
• Durable Design: IP54-rated for dust and water resistance, ensuring reliable operation in challenging environments.
• Extended Flight Time: Up to 50 minutes of operation per flight for sustained productivity.
• Precise Navigation: Integrated RTK module delivers ±3cm positioning accuracy for critical tasks.
• Autonomous Functionality: Optimized for seamless integration with DJI Dock 2.
• Safety-Enhanced Operation: 6-directional obstacle sensing system ensures safe and accurate navigation.

Detailed Specification

Aircraft Specifications

Attribute	Specification
Weight	3.1 lbs. (1410g)
Max Take-Off Weight	3.54 lbs.
Dimensions	13.2"x15.66"x6" (335x398x153mm)
Max Flight Time	50 min
Max Hover Time	40 min
Max Operational Range	6.21 mi. (10 km)
Max Wind Resistance	26.8 mph (operation), 17.9 mph (takeoff/landing)
IP Rating	IP54
Max Take-Off Altitude	1.55 mi. (2500m)
Operating Temperature	20°C to 45°C

Imaging Systems

Feature	Wide-Angle
Sensor	1/1.32-inch CMOS
Focal Length	24mm
Resolution	48MP
Zoom	N/A

Feature	Telephoto
Sensor	1/2-inch CMOS
Focal Length	161mm
Resolution	12MP
Zoom	56x hybrid zoom

Feature	Thermal
Sensor	Uncooled VOx Microbolometer
Focal Length	40mm
Resolution	640x512 @ 30fps (normal), 1280x1024 @ 30fps (super-resolution)
Zoom	28x digital zoom

Flight Performance

Attribute	Normal Mode
Max Ascent Speed	13.4 mph
Max Descent Speed	13.4 mph
Max Speed	33.5 mph (forward)

Attribute	Sport Mode
Max Ascent Speed	17.8 mph
Max Descent Speed	13.4 mph
Max Speed	47 mph (forward)

In Package

• DJI Matrice 3TD Aircraft Body
• Integrated RTK Module
• Wide-Angle, Telephoto, and Thermal Cameras
• 2x Intelligent Flight Batteries
• Battery Charging Hub
• USB A to A Cable
• Carrying Case
• Installation Tools and Accessories
• DJI Care Enterprise (comprehensive accidental coverage plan)
